High speed three side sealing bag making machine for all kinds of laminated film. Max roll width 1250 mm, roll diameter Φ900 mm, speed 160 pcs/min, bag width 600 mm, bag length 50-400 mm (multi-feed up to 6x), total power 42.75 kW.
JYZD 3 Side Sealing High Speed Bag Making MachineHigh speed three side sealing bag making machine for all kinds of laminated film. Max roll width 1250 mm, roll diameter Φ900 mm, speed 160 pcs/min, bag width 600 mm, bag length 50-400 mm (multi-feed up to 6x), total power 42.75 kW.Applicable materials: All kinds of heat-sealable laminated filmTechnical parameters:Model: JYZD-600Material: All kinds of laminated filmMax. raw roll width: 1250mmMax. raw roll diameter: Φ900mmBag making speed: Three-side sealing 160 pcs/min (actual speed depends on material and bag type)Bag width: 600mmBag length: 50-400mm (one-time pull length); multi-feed used above 370mm (max 6 times)Total power: 42.75kWCooling water: 15 L/minAir pressure: 0.6MPaWeight: approx. 5500kgDimensions (L×W×H): 8500×1700×1950mmManufacturer: Wenzhou Jinyi Machinery Co., Ltd. (Brand: JINYI), Ruian, Zhejiang, China.Brand: JINYIPlace of origin: Zhejiang, ChinaKeywords: three side sealing bag making machine; pouch making machine; laminated film bag machine
| Material | All kinds of laminated film |
|---|---|
| Max. raw roll width | 1250mm |
| Max. raw roll diameter | Φ900mm |
| Bag making speed | Three-side sealing 160 pcs/min (actual speed depends on material and bag type) |
| Bag width | 600mm |
| Bag length | 50-400mm (one-time pull length); multi-feed used above 370mm (max 6 times) |
| Total power | 42.75kW |
| Cooling water | 15 L/min |
| Air pressure | 0.6MPa |
| Weight | approx. 5500kg |
| Dimensions (L×W×H) | 8500×1700×1950mm |
| Variants | JYZD-600 |
